Rada 222-T3 DK Thermostatic Mixing Valve

222-T3 DK 3/4″ thermostatic mixing valve incorporating Radatherm cartridge
Suitable for under-bath/duct mounting
Unbeatable temperature control
Supplied with check valves and strainers
Approved for use in all UK healthcare premises
Suitable for duct mounting or under-basin
Adjustable inlet elbows for variable installation
Supplied with 3/4 inch flat faced union connectors terminating in 22mm compression connections
WRAS approved
Unique Patented “Radatherm” service-free cartridge
Tamperproof temperature setting (locked cap)
Designed to be concealed in a duct/cupboard
Must be used with a separate outlet flow control such as a tap
Factory pre-set maximum outlet temperature: 43°C
Minimum temperature differential, blend to either supply: 12°C
Minimum dynamic supply pressure: 0.15 bar
