Geberit Alpha 98cm Height Frame & Cistern for Wall-Hung WC

Geberit 98cm Height Alpha Frame & Cistern for Wall-Hung WC
Duofix frame with Alpha concealed cistern 12cm
5.8 / 3 litres
Robust and reliable solution for modern bathroom installations
Suitable for under window installations or for part-height installations in drywall construction
Engineered to support up to 400kg (63 stone), ensuring stability without wobbling
Wall-mounted WC installation keeps the floor clear of pipes and exposed surfaces where dirt and bacteria could gather
Simple maintenance
Designed with acoustic solutions for quiet operation
Dual Flush Technology – Choose between two flush volumes to conserve water
Leakproof Design – Cistern blow-moulded in a single piece to prevent leaks, ensuring reliability
Compatibility – Works with Geberit pneumatic flush buttons, making it versatile for various bathroom aesthetics and environments
Easy Maintenance – Flush plate removal grants quick access to all essential components
Powder Coated Steel, Blow Mold Plastic, Galvanised Feet
Statically self-supporting frame, protected against corrosion with powder coating
Galvanised leg supports protected against corrosion
For front actuation, suitable for dual flush
Water supply connection on the rear or top centre

Scope of delivery:
• Water supply connection unit R 1/2″, with integrated angle stop valve and adapter ring
• Protection box for service opening
• 2 wall anchors
• Connection set for WC, ø 90mm
• Connection bend 90° made of PE-HD, ø 90mm
• Adaptor socket made of PE-HD, ø 90 / 110mm
• Fastening and protection material
